74238

Product Description

✅ General Specification: ➡️ IC Type: 3-to-8 Line Decoder / Demultiplexer ➡️ Logic Family: TTL (74 Series) ➡️ Supply Voltage (VCC): 5V DC (4.75V – 5.25V) ➡️ Input Lines: 3 (A, B, C) ➡️ Output Lines: 8 (Y0 – Y7) ➡️ Output Type: Active HIGH outputs ➡️ Enable Inputs:   • G1 – Active HIGH   • G2A, G2B – Active LOW ➡️ Logic Function: One-of-eight decoding when enabled ➡️ Propagation Delay: ~15 ns (typical) ➡️ Power Consumption: Low (Standard TTL) ➡️ Output Drive Capability: TTL compatible ➡️ Operating Temperature: 0°C to 70°C ➡️ Package Type: DIP-16 ➡️ Pin Count: 16 pins ➡️ Pin Spacing: 2.54 mm (Breadboard friendly) ➡️ Weight: ~1.2 grams 🧠 Working Principle: ➡️ When enabled, one output goes HIGH based on the 3-bit binary input ➡️ All other outputs remain LOW ➡️ Works as both decoder and demultiplexer
