7420

Product Description

✅ General Specification: ➡️ IC Type: Dual 4-Input NAND Gate ➡️ Logic Family: TTL (74 Series) ➡️ Number of Gates: 2 NAND gates per IC ➡️ Inputs per Gate: 4 Inputs ➡️ Operating Voltage: 4.75V – 5.25V DC (Typical: 5V) ➡️ Input Logic Level: TTL Compatible ➡️ Output Logic Level: TTL ➡️ Propagation Delay: ~10 ns (typical) ➡️ Power Consumption: TTL standard, low power ➡️ Operating Temperature: 0°C to 70°C ➡️ Package Type: DIP-14 ➡️ Mounting Type: Through Hole ➡️ Dimensions: Standard DIP IC size ➡️ Weight: ~1.2 grams 🛠 Applications: ✔️ Digital logic & combinational circuits ✔️ Logic gating & signal inversion ✔️ Control & automation systems ✔️ Microprocessor / logic interfacing ✔️ Educational digital electronics labs 🔌 Pin Configuration Highlights: ➡️ Gate-1 Inputs: A1, B1, C1, D1 → Output Y1 ➡️ Gate-2 Inputs: A2, B2, C2, D2 → Output Y2 ➡️ Power Pins: VCC (5V), GND 📘 Logic Function: ➡️ Output LOW only when all inputs are HIGH ➡️ Output HIGH for any other input combination
